Flooded Dry-changed maintenance-free lead-acid bat

Product characteristics:
  • 1.This series is flooded MF battery for motorcycle application
  • 2.This product use thin plate with special formula, enhanced the reaction area to increase high currency discharge performance, thus it has good starting performance.
  • 3.Special process control to ensure long shelf life in dry status and good real time use performance.
  • 4.Use good machinery strength and excellent insulating material made battery container. Meanwhile stable hot welding technology and well-designed structure. Therefore, battery has good anti-vibration performance.
  • 5.Battery cover design is labyrinth style, Special structure will separate gas from liquid and acid will return quickly.
  • 6.Use acid filter to prohibit acid fog out together with gas.
Type Voltage(V) Capacity(AH) Outer diameter(±2mm) Deployment diagram Terminal type
Length Width Height
6M4-2A 6 4 70 70 95 导线
12M2.5L-C 12 2.5 80 70 105 导线
12M3L-A 12 3 98 56 110 扁极柱
12M4-3B 12 4 120 70 92 方极柱
12M5S-3B 12 5 120 60 130 扁极柱
12M5.5-3B 12 5.5 120 60 130 扁极柱
12M6A-3B 12 6 135 70 95 扁极柱
12M6.5-3A 12 6.5 140 68 101 扁极柱
12M6.5-3B 12 6.5 140 68 101 扁极柱
12M6.5A-3B 12 6.5 135 70 110 扁极柱
12M7C-4B 12 7 150 88 95 扁极柱
12M7E-4B 12 7 150 88 95 方极柱
12M7D-3B 12 7 110 72 130 方极柱
12M7A-3A 12 7 150 60 130 扁极柱
12M7A-3B 12 7 150 60 130 扁极柱
12M7A-4B 12 7 150 60 130 扁极柱
12M7-3B 12 7 135 75 133 扁极柱
12M7-4B 12 7 135 75 133 扁极柱
12M7-4A 12 7 135 75 133 扁极柱
12M8-4A 12 8 135 75 133 扁极柱
12M9-3B 12 9 135 75 139 扁极柱
12M9-4B-1 12 9 135 75 139 扁极柱
Part of the product show:
  • Type:12M7A-3B
    Voltage:12
    Capacity:7
    Terminal type:
    扁极柱

  • Type:12M7A-3A
    Voltage:12
    Capacity:7
    Terminal type:
    扁极柱

  • Type:12M5S-3B
    Voltage:12
    Capacity:5
    Terminal type:
    扁极柱

  • Type:12M3L-A
    Voltage:12
    Capacity:3
    Terminal type:
    扁极柱

  • Type:12M6-3B
    Voltage:12
    Capacity:6
    Terminal type:
    扁极柱
