Valve-regulated dry-charged lead acid battery

Product characteristics:
  • 1.This product is VRLA dry charge MF battery
  • 2.This product use thin plate with special formula, enhanced the reaction area to increase high currency discharge performance, thus it has good starting performance.
  • 3.Special process control to ensure long shelf life in dry status and good real time use performance.
  • 4.Ensure accurate acid volume with unique combined six acid bottles, easy for filling.
  • 5.Use good machinery strength and excellent insulating material made battery container. Meanwhile stable hot welding technology and well-designed structure. Therefore, battery has good anti-vibration performance.
Type Voltage(V) Capacity(AH) Outer diameter(±2mm) Deployment diagram Terminal type
Length Width Height
MTX2.5L-BS 12 2.2 80 70 105 导线
MTX3L-BS 12 3 98 55 108 扁极柱
MTX4L-BS 12 4 113 70 85 方极柱
MTX5AL-BS 12 5 120 61 131 扁极柱
MTX5L-BS 12 5 113 70 105 方极柱
MTX6.5L-BS 12 6.5 138.5 66.5 98 扁极柱
MTX7L-BS 12 7 113 70 130 方极柱
MTX7-BS 12 7 135 75 132 扁极柱
MTX7AL-BS 12 7 135 75 132 扁极柱
MTX7BL-BS 12 7 148 59.5 130 扁极柱
MTX7A-BS 12 7 150 87 93 方极柱
MTX9-BS 12 9 150 87 105 方极柱
MTX9A-BS 12 9 135 75 132 方极柱
MTX10-BS 12 9 135 75 135 方极柱
MTX12-BS 12 11 151 87.5 130 方极柱
MTX14-BS 12 13 150 86.5 145 方极柱
MTX20L-BS 12 19 174.5 87 154 方极柱
Part of the product show:
  • Type:MTX20L-BS
    Voltage:12
    Capacity:19
    Terminal type:
    方极柱

  • Type:MTX7A-BS
    Voltage:12
    Capacity:6
    Terminal type:
    方极柱

  • Type:MTX7L-BS
    Voltage:12
    Capacity:6
    Terminal type:
    方极柱

  • Type:MTX5L-BS
    Voltage:12
    Capacity:4
    Terminal type:
    方极柱

  • Type:MTX6.5L-BS
    Voltage:12
    Capacity:6
    Terminal type:
    扁极柱
